Serge Ferrari Soltis Horizon 86 - Zip Perde Kumaşlar

Solar and light properties (EN 14501)

Product	Color	TS	RS	AS	TV n-h	ISO 52022-3* Type “D“ glazing
Product	Color	TS	RS	AS	TV n-h	g_tot^e	g_totⁱ
86-50690		28	61	11	27	0.11	0.14
86-2175		30	57	13	28	0.11	0.16
86-2012		18	27	55	16	0.08	0.24
86-2135		24	39	37	22	0.09	0.21
86-2171		22	36	42	20	0.08	0.21
86-2167		17	14	69	17	0.07	0.26
86-2047		17	7	76	17	0.07	0.28
86-51176		14	5	81	14	0.07	0.29

TS: Solar Geçirgenlik (%)	Solar Transmission (%)
RS: Güneş Işını Yansıtma %	Solar Reflection in %
AS: Güneş Işını Emme %	Solar absorption in %
TS + RS + AS = Gelen enerjinin %100’ü	= 100% of the incident energy
TV n-h: Normal Görünür ışık geçirgenliği - yarı küresel olarak %	Normal Visible light transmission - hemispherical in %
g_{to^e: Dış Güneş Faktörü}	External Solar Factor
g_{tot^{i: İç Güneş Faktörü}}	Indoor Solar Factor

Takes into account the spectral values of glazing transmission and reflection + blind complex for calculating the solar factor g ^tot _{. Type“D”glazing: insulating double glazing with low emissivity on
surface 2 (4 + 16 + 4; Argon filling) g = 0.32 - U = 1.1}

	Teknik özellikler / Technical properties	Standartlar / Standards
Açıklık faktörü / Openess factor	14%
Ağırlık / Weight	380 g/m²	EN ISO 2286-2
Kalınlık / Thickness	0.45 mm
Genişlik / Width	267 cm
	Rulo uzunluğu / Length of rolls
Standart format - uzunluk 267 cm Standard format - length in 267 cm	40 lm
	Fiziksel özellikler / Physical properties
Kopma mukavemeti (çözgü/zemin) Tensile strength (warp/weft)	230/160 daN/5 cm	EN ISO 1421
Yırtılma mukavemeti (çözgü/zemin) Tear strength (warp/weft)	45/20 daN	DIN 53.363
	Alev geciktiricilik / Flame retardancy
Derecelendirme / Rating	B1/DIN 4102-1• BS 7837• BS 5867• Schwerbrennbar-Q1-Tr1/ONORM A 3800-1 Classe 1/UNI 9177-87• M1/UNE 23.727-90 VKF 5.2/SN 198898 • 1530.3/AS/NZS G1/GOST 30244-94 • Method 1/NFPA 701- CSFM T19 • Class A/ASTM E84
Yangın Sınıfı / Euroclass	B-s2,d0	En 13501-1
	Yönetim sistemleri / Management systems
Kalite / For quality		ISO 9001
	Sertifikalar, Etiketler, Garantiler, Geri dönüşüm / Certifications, Labels, Warranties, Recycling

Snow White86-50690

Champagne86-2175

Pepper86-2012

Sandy Beige86-2135

Boulder86-2171

Concrete86-2167

Anthracite86-2047

Deep Black86-51176
